File Extensions

• .dmg - Apple Disk Image file. This is commonly seen in software installers
  • Mount and access data inside the files
  • A bit of a combination between a ZIP and ISO file
• .kext
  • Kernel extension -> Runs in kernel space
  • Kext bundles are the OS X version of a driver
  • Actually a directory you can browse the contents of
  • Elevated privileges
• .plist
  • Property List -> Store settings for users or bundles or apps
  • Store XML content
  • Some are stored in binary format and can be converted back to XML
• .app
  • Apple application
  • Structured directory you can browse through
• .dylib
  • Dynamic library -> Equivalent to a DLL (Dynamic Link Library)
  • Loaded at run time
• .pkg
  • Same as xar (eXtensible ARchive format) with a different file extension and hierarchy
  • Pkgutil is built into the command line
  • installer can be used to install these contents
• Macho-O
  • Executable format of binaries for OS X
  • Similar to ELF in Linux and PE in Windows

File Hierarchy Layout

• /Applications
  • Apps will be installed in this directory
  • All users can access apps installed here
• /Library
  • Holds many subdirectories by default
    • Some related to app preferences, caches, and logs
  • Exists in a user directory and the root directory
    • Some data is stored on a per user basis
• /System
  • Files required to make OS X run
  • Most will be specific to Apple
• /Users
  • Equivalent to the Linux /home directory
  • Every user will have their own directory
• /Volumes
  • Any drives mounted to your system are shown here
  • Root hard drive is shown as a soft link pointed at ‘/’
• /.vol
  • Related to a virtual file system that exists on top of HFS+ (or HFS Standard)
  • File records on the hard drive are stored by inode numbers and not file names
  • Interact with these files via their inode number
  • ‘ls’ will not show any contents of this directory
• /bin
  • Command-line binaries
    • cat, ls, echo, ifconfig, ps, etc.
• /usr
  • Configurations and system binaries
• /cores
  • May or may not exist
  • Stores core dumps
• /sbin
  • Essential system binaries
    • Related to admin
• /dev
  • Short for ‘device’
  • Unix treats everything as a file -> hardware devices are stored here and sometimes Bluetooth connected devices
• /etc
  • Configuration files
  • Symbolic link to /private/etc
• /tmp
  • Temporary files
  • Files are deleted after 3 days by default
  • Soft link to /private/tmp
• /private
  • Contains sensitive data, resources, and configuration files
  • Four subdirectories
    • /etc
      • Configuration files and scripts for the entire system
    • /tftpboot
      • Blank folder that stores TFTP data related to NetBoot
    • /tmp
      • Temporary files
    • /var
      • System-related cache files
• /var
  • Log files
  • Console app is the easiest way to view these logs
  • Constantly changing or updating files in the directory

Miscellaneous Files

• Hidden Files and Directories
  • Start with a ‘.’ Ex. /.folder
  • Can be viewed using ls -a to see hidden files and directories
• .DS_Store
  • Can find this in any directory you’ve browsed to with Finder
  • Holds attributes and customizations of the directory it is stored in
    • Icons, views, and finder colors
• .Spotlight-V100
  • Created in root directory of every volume in the system
  • Index information for reference by the search tool, Spotlight
• .metadata_never_index
  • If this file is at the root of a volume, Spotlight will not index the volume
    • Recovery Partition is an example of a volume that will have this
• <FolderName>.noindex
  • Will not be indexed by Spotlight
  • Can be used nefariously to ensure a malicious file does not show up in Spotlight

Key File Artifacts

• ~/Library/Preferences/com.apple.LaunchServices.QuarantineEventsV*
  • SQL database with information about files downloaded form the internet
  • Works with the com.apple.quarantine extended attribute
• ~/.bash_history
  • Lists recent commands executed via the bash shell
  • Bash interactive sessions will write to this file after the shell exits
• /etc/profile
  • Can be used to modify bash environment upon loading an interactive session
    • Includes variable commands and functions
  • Can point to bash debug scripts to allow for hooking inside of different executables
  • Apply to interactive bash sessions system wide
• /etc/bashrc
  • By default, this file is imported by /etc/profile
  • System wide
• ~/.bash_profile, ~/.bash_login, ~/.profile, ~/.bashrc
  • Additional files that allow for adding variables and functions to the bash shell once loaded
  • Some can only be loaded under certain circumstances
• ~/.bash_logout
  • Can hold a list of commands to execute when a user logs out of a bash shell
• /var/log/system.log
  • Main OS X system log
  • Store details about operating system errors and security
  • Modern OS X stores ssh, ftp, and other information
  • Incredibly valuable for security -> should not be disabled
  • com.apple.syslogd.plist is responsible for the execution of syslogging at startup
    • Confirm syslogging is not disabled by searching for com.apple.syslogd inside of the ‘launchctl list’ output
• /private/var/log/asl/*.asl
  • Apple System Logs
    • Alternative to system.log
    • Can contain more information
  • Can print the logs ordered by a UTC timestamp using ‘syslog -T UTC’
• ~/Library/Preferences/com.apple.recentitems.plist
  • Recently accessed files and applications from Finder
• ~/Library/Preferences/com.apple.finder.plist
  • Details regarding Finder and what is seen when it is opened
• ~/Library/Preferences/com.apple.loginitems.plist
  • Items that are launched upon start up
• ~/Library/Logs/DiskUtility.log
  • Log file for DiskUtility
    • Information on when drives were formatted, including USB drives
• /Library/Preferences/SystemConfiguration/com.apple.airport/preferences.plist
  • Contains info about wireless access points the system has connected to
  • ‘LastConnected’ key is useful as it contains the timestamp for when an access point was last connected
• /private/etc/resolv.conf
  • DNS nameservers to be used
• /private/var/db/launchd.db/com.apple.launchd/overrides.plist
  • Contains a list of launch agents that have been permanently unloaded
    • Syslog plist being unloaded would be a red flag
• /private/etc/kcpassword
  • Exists if autologin is enabled
  • User’s password is masked with an XOR key
• /private/etc/sudoers
  • List of users allowed to log into the root account
• /private/etc/hosts
  • Force resolves IP addresses to domains
• /private/var/log/fsck_hfs.log
  • Fsck_hfs utility log
    • Runs checks and repairs on a HFS+ file system
• /Library/Logs/AppleFileService/AppleFileServiceError.log
  • Errors related to the Apple Filing Protocol
    • Used to share files across devices
  • Apple now focuses on using SMB -> AFP is still available to be used
• /var/log/apache2/access_log
  • Apache web server activity log
• /var/log/apache2/error_log
  • Errors related to the httpd service
• /var/log/opendirectoryd.log
  • Open Directory is a launchd process that allows the operating system to access a variety of directory servers
• /var/log/wifi.log
  • Results about different wireless details
  • Can show if somebody was on a network at a certain time
  • Contains info about wireless connections such as Bluetooth
• /var/log/appfilewall.log
  • Application Firewall logs
    • System Settings > Security & Privacy > Firewall
  • Uses pfctl rule to accomplish tasks
• /var/log/hdiejectd.log
  • Errors related to drives failing to unmount
• /var/log/install.log
  • Details about app updates, upgrades, and installs
• /var/audit/*
  • Related to the auditd daemon
  • Can monitor items at the kernel level
  • By default, records when root logins are attempted and when a password is changed
  • Stored in binary format -> use praudit to read
